Jack W. O'Sullivan

It is understood gait has the potential to be used as a window into neurodegenerative disorders, identify markers of subclinical pathology, inform diagnostic algorithms of disease progression and measure the efficacy of interventions. Dogs’ gaits are frequently assessed in a veterinary setting to detect signs of lameness. Despite this, a reliable, affordable and objective method to assess lameness in dogs is lacking. Most described canine lameness assessments are subjective, unvalidated and at high risk of bias. This means reliable, early detection of canine gait abnormalities is challenging, which may have detrimental implications for dogs’ welfare. In this paper, we draw from approaches and technologies used in human movement science and describe a system for objectively measuring temporal gait characteristics in dogs (step-time, swing-time, stance-time). Asymmetries and variabilities in these characteristics are of known clinical significance when assessing lameness but presently may only be assessed on coarse scales or under highly instrumented environments. The system consists an inertial measurement unit, containing a 3-axis accelerometer and gyroscope coupled with a standardized walking course. The measurement unit is attached to each leg of the dog under assessment before it is walked around the course. The data by the measurement unit is then processed to identify steps and subsequently, micro-gait characteristics. This method has been tested on a cohort of 19 healthy dogs of various breeds ranging in height from 34.2 cm to 84.9 cm. We report the system as capable of making precise step delineations with detections of initial and final contact times of foot-to-floor to a mean precision of 0.011 s and 0.048 s, respectively. Results are based on analysis of 12,678 foot falls and we report a sensitivity, positive predictive value and F-score of 0.81, 0.83 and 0.82 respectively. To investigate the effect of gait on system performance, the approach was tested in both walking and trotting with no significant performance deviation with 7249 steps reported for a walking gait and 4977 for a trotting gait. The number of steps reported for each leg were approximately equal and this consistency was true in both walking and trotting gaits. In the walking gait 1965, 1790, 1726 and 1768 steps were reported for the front left, front right, hind left and hind right legs respectively. 1361, 1250, 1176 and 1190 steps were reported for each of the four legs in the trotting gait. The proposed system is a pragmatic and precise solution for obtaining objective measurements of canine gait. With further development, it promises potential for a wide range of applications in both research and clinical practice.

Background: The use of accelerometers in bio-logging devices has proved to be a powerful tool for the quantification of animal behaviour. While bio-logging techniques are being used on wide range of species, to date they have only been seldom used with non-human primates. This is likely due to three main factors: the long tradition of direct field observations, a difficulty of attaching bio-logging devices to wild primates and the challenge of deciphering acceleration signals in species’ with remarkable locomotor and behavioural diversity. Here, we overcome these aforementioned obstacles and provide methodology for identification of behaviours from accelerometer data of wild chacma baboons (Papio ursinus) in Cape Town, South Africa.
Results: We apply machine learning techniques to process complex accelerometer data, collected by bespoke tracking collars to quantify a range of behaviours (focusing on locomotion and foraging behaviour). We successfully identify six broad state behaviours that represent 93.3% of the time budget of the baboons. Resting, walking, running and foraging were all identified with high recall and precision representing the first classification of multiple behavioural states from accelerometer data for a wild primate.
Conclusion: Our ‘end to end’ process—from collar design and build to the collection and quantification of acceleration data—provides advantages over gathering data by traditional observation, not least because it affords data collection without the presence of an observer which may affect an animal’s behaviour. Furthermore, our methodology and findings open new possibilities for the fine-scale study of movement and foraging ecology in wild primates, and in particular our baboon study population which is in conflict with people.

Background: Accelerometer-based technologies could be useful in providing objective measures of canine ambulation, but most are either not tailored to the idiosyncrasies of canine gait, or, use un-validated or closed source approaches. The aim of this paper was to validate algorithms which could be applied to accelerometer data for i) counting the number of steps and ii) distance travelled by a dog. To count steps, an approach based on partitioning acceleration was used. This was applied to accelerometer data from 13 dogs which were walked a set distance and filmed. Each footfall captured on video was annotated. In a second experiment, an approach based on signal features was used to estimate distance travelled. This was applied to accelerometer data from 10 dogs with osteoarthritis during normal walks with their owners where GPS (Global Positioning System) was also captured. Pearson’s correlations and Bland Altman statistics were used to compare i) the number of steps measured on video footage and predicted by the algorithm and ii) the distance travelled estimated by GPS and predicted by the algorithm.
Results: Both step count and distance travelled could be estimated accurately by the algorithms presented in this paper: 4695 steps were annotated from the video and the pedometer was able to detect 91%. GPS logged a total of 20,184 m meters across all dogs; the mean difference between the predicted and GPS estimated walk length was 211 m and the mean similarity was 79%.
Conclusions: The algorithms described show promise in detecting number of steps and distance travelled from an accelerometer. The approach for detecting steps might be advantageous to methods which estimate gross activity because these include energy output from stationary activities. The approach for estimating distance might be suited to replacing GPS in indoor environments or others with limited satellite signal. The algorithms also allow for temporal and spatial components of ambulation to be calculated. Temporal and spatial aspects of dog ambulation are clinical indicators which could be used for diagnosis or monitoring of certain diseases, or used to provide information in support of canine weight-loss programmes.

Piling is an understudied group behaviour where chickens gather in dense clusters. It appears to be widespread in commercial laying hens, leads to mortalities (smothers) and impacts production. Automated detection of piling could support: (i) stockpersons to reduce the behaviour and (ii) scientific efforts to study the behaviour. Computer vision-based classification is increasingly used in animal behaviour research to accelerate annotation of datasets. Here we aimed to automatically detect piling using the well-established residual network (ResNet) architecture convolutional neural network (CNN) to classify video frames of piling and non-piling chickens in commercial free-range laying farms. Data from 10 flocks (8 for training, 2 for testing) were used. The model achieved high classification accuracy, correctly identifying 89.6% of individual frames and 90.9% of aggregated events, though misclassifications at both levels were driven primarily by false negatives (16.2% for frames and 16.8% for events). Cases of misclassification could arise from not accounting for the temporal aspect of piling, human annotation error, image quality, flock-specific characteristics or ambiguous cases. ResNet demonstrated good performance for classifying piling from non-piling from still frames in brown laying hens in commercial houses but would need further training data to be robust to different housing types and chicken breeds.
